CGR AL e - Enthusiast
Shimano 105 12-Speed

  1. £3,199
Ride it all, link up tarmac cols with fun inducing trail descents. With powerful pedal assistance at the push of a button, the CGR AL e is ready for any season and riding scenario.
Product code: BCGRALE7100D

...And Many Ways To Pay...

Description

Featuring a sleek aluminium frame, powerful electric motor, and versatile tyre clearance, the CGR AL e provides the perfect blend of performance and all-day comfort for mixed-surface adventures. In Enthusiast specification, the CGR AL e is paired with Shimano’s 105 12-speed groupset, robust and reliable Mavic Allroad wheels with integrated motor, 40 mm Schwalbe G-One tyres, and a Selle Italia X3 Boost saddle.

Groupset

Shimano’s first and only 12-speed mechanical groupset is the latest addition to the premium road family. 105 7100 combines pure cycling with pure craftmanship. Inspired by 105 Di2, this versatile drivetrain delivers the wide gear range, hand-friendly ergonomics, and all-condition braking confidence you’ve always craved. Developed from Shimano’s Science of Speed philosophy, 105 mechanical raises accessible performance to a whole new level.

Groupset

Wheelset

Designed to ride smoother and faster on dirt, gravel, and road, you can ride it all with confident control with the lightweight, durable, and responsive Mavic Allroad wheels with integrated motor. Paired with Schwalbe G-One Tyres 40mm in tanwall design, these tyres are a multi-purpose gravel tyre, suited to everything from hidden dirt tracks to road routes.

Wheelset

Handlebars

LEVEL alloy handlebars offer a shorter drop and reach, providing swift transitions from the tops and hoods to the drops with minimal change of position. Their ergonomic design ensures almost any cyclist can find their optimal ride position for enhanced comfort on rides of any distance. Wrapped in a comfortable LEVEL bar tape and neatly matched with a LEVEL alloy handlebar stem.

Handlebars

Saddle

A lightweight LEVEL alloy seat post paired with an ergonomic Selle Italia X3 saddle provides riders with the outstanding comfort and support they need to explore every tarmac road or gravel trail.

Saddle

Size

To assist you in selecting the correct size, simply find your height on the graphic. It illustrates our recommendations so you can be confident that the size you order will be correct. If you find that your height is between sizes, we recommend you opt for the smaller size.

Size

Geometry

SizeXSSMMDLGXL
Rider Height5'4" - 5'7" (162 - 170cm)5'7" - 5'9" (170 - 175cm)5'9" - 5'11" (175 - 180cm)5'11" - 6'1" (180 - 185cm)6'1" - 6'4" (185 - 194cm)
A - Seat Angle74.5°74.0°73.5°73.0°72.5°
B -Top Tube (mm)520540555570590
C - Head Angle70°.571°71.5°72°72°
D - Offset (mm)5050505050
E - Head Tube (mm)140150170190200
F - BB Drop6969696969
G - Seat Tube (mm)470510530555580
RC - Chainstay (mm)435435435435435
FC - Front Centre (mm)595605611616630
Reach (mm)365377380383395
Stack (mm)556568589610620
WB - Wheelbase (mm)1021.510311036.81041.81055

Frequently Asked Questions

A conveniently situated handlebar control unit allows you to set the level of assistance you require for the terrain ahead and displays the battery charge remaining.

The button mounted on the top tube indicates the remaining battery life at a glance using a simple traffic light system: White = 75% capacity or more remaining, Green = 50-75%, Amber = 25-50%, Red = 15-25%, Slow Red Flash = 10-15% and Rapid Red Flash = 10% or less remaining. You can also keep track of the remaining battery life using the MAHLE SmartBike Systems companion app.

Yes. Our e-bikes are pedal-assisted models (pedelecs) and always require rider input.

There’s no need to worry; being a pedal-assisted model means you're always in full control. When an assistance level is selected, the motor simply provides a little extra boost to amplify your pedalling efforts and never takes over.

No. Pedal-assisted electric bikes don't require you to hold a valid driver’s licence, pay road tax or take out insurance.

Simply plug the bike into a household power socket using the supplied charger and cable. The optional range extender can also be used to charge the main battery whilst you are on the move.

The electric components used on our e-bikes are IP54 rated. They can be used in inclement weather conditions and are protected against splashing, but not against full immersion or when subjected to pressurised water from a hose pipe or jet wash. When transporting the bike outside of a vehicle, a waterproof cover should be utilised to protect the electronic components from water damage during such transportation. As with any bike, we recommend thoroughly cleaning and drying the bike after any wet weather ride to ensure the peak performance of your bike.

You can test-ride any of our e-bikes and receive expert buying advice at our flagship Clitheroe showroom. Please contact the showroom in advance so that we can ensure that any suitable bikes you wish to test are available for your visit. Alternatively, you can hire the e-bike from E-Venture Bikes in Keswick; the rental cost will be deducted from your purchase if you decide to purchase one of our e-bikes.

All e-bikes can be purchased via all the major Cycle to Work scheme providers. The government has even abolished the £1000 limit, making obtaining an e-bike on Cycle to Work more beneficial than ever.

The MAHLE X35 SmartBike system assists you up to a maximum of 15mph, at which point (by law, as with all e-bikes in the UK) the assistance cuts out. If you drop back below 15mph, the system will re-engage until turned off.

The battery range of the CGR AL e depends on several factors, including rider weight, route profile and temperature. A rider of 90kg on a varied route, including climbs, descents and flats, can expect an approximate range of up to 60 miles. An optional range extender is also available for all of our e-bikes, effectively doubling the bike's available range.

The CGR AL e includes discreet mounts to fit a rear pannier rack, handling all your luggage-carrying needs.

There's ample clearance for 650b x 48mm or 700c x 45mm tyres without mudguards or 40mm with guards fitted.

The MAHLE SmartBike system requires a bolt-on fitting rear wheel; the front is a 100/120/M12*P1.5 bolt-thru axle.

A medium-sized frame fitted with SRAM Apex weighs approximately 13.5kgs, making it one of the lightest e-bikes of its type in the world. We also make the lightest range of e-road bikes in the world.

The battery can be accessed via the bottom bracket. The press-fit bottom bracket has to be removed first to facilitate this removal. The motor is also easy to access and replace. We recommend that a trained mechanic carry out this work.

The battery can reach up to 500 charging cycles while retaining up to 90% of its capacity, as long as its care and maintenance are adequate. Please refer to our battery care blog for our top tips and recommendations to maximise battery life. Use only the original MAHLE charger supplied with your bike.

Disconnect the cable to the rear wheel motor by unclipping the connector on the chainstay. Then, use an 8mm Allen key to loosen the nuts on the rear axle, and reverse the process once the puncture has been repaired.

The frame is warranted against manufacturing defects for a period of 3-years. All other parts are covered by the manufacturer's standard warranty. The MAHLE system carries a 2-year warranty.

Due to the many different systems people use, pedals aren't included. However, you can add a set of pedals to your order when configuring the bike.
